Advantest R3671 20Hz-13GHz Signal Analyzer



•Frequency Range: 20Hz to 13GHz
•Dynamic Range: -158 dBm – -96 dBm
•Frequency Resolution: 0.01 Hz
•Frequency Spans: 20Hz – 13GHz
•Input Impedance: 50ohms
•Amplitude Accuracy: +/- 0.2 dB – +/- 0.3 dB
•Amplitude Range: +20 dBm – +30 dBm



Artikelnummer: 1366 Kategorien: ,

Beschreibung

The Advantest R3671 is one of the new measuring instruments for this new era of test and measurement requirements. The R3671 is a high performance signal analyzer. Employing its unique RF technology, the it achieves an Average Display Noise Level of -158dBm *1), a Third Order Intercept Point (TOI) specification of +26dBm *2), and a signal purity of -122dBc/Hz *3) to enable measurements over a wide dynamic range. The R3671 also has a unique noise correction function that enhances its dynamic range (-84dBc [typical]) for W-CDMA adjacent leakage power (ACLP) measurements. It supports a standard broadband modulation analysis function (bandwidth 25MHz). This functionality enables testing of next generation digital radio communication standards.
•Built-in High-Performance Digital Modulation Signal Generator (OPT.72)
•Various Modulation Analysis Options: W-LAN (IEEE802.11a/b/g), W-CDMA (HSDPA), cdma2000 (1xEV-DV)
