Aim TTi PSA1302 1,3GHz portable RF Spectrum Analyzer


•Frequency range: 1MHz to 1300MHz
•Resolution bandwidth:s  1MHz, 280kHz or 15kHz
•Typical noise Floor: -96dBm
•Reference level: -20dBm or 0dBm (87dBµV or 107dBµV)
•Display range: 85dBm from reference level
•Input impedance:   50Ω

Artikelnummer: 00301 Kategorien: ,


The Aim TTi PSA1302 is a fully portable RF spectrum analyzers that incorporate a high resolution colour TFT touch screen. It builds upon the success of the PSA-T series in offering a lightweight and truly handheld instrument that incorporates an extensive feature set. An improved user interface is combined with many new hardware and software features and a ruggedized casing.

•Trace modes of normal, single, peak hold and average
•Zero span mode with AM and FM audio demodulation
•Live, View and Reference traces in contrasting colors
•Twin markers with readout of absolute & difference values
•Measurement in dBm or dBuV, mV or uW
•Smart marker movement with selectable peak tracking
•Auto-find automatically sets sweep parameters for the highest signal found
•Unlimited storage for waveforms, set-ups and screens
•User assignable file names, file stamping from real-time clock
•USB interfaces for Flash drives and PC connection
•Comprehensive status and context sensitive help screens
•4.3″ colour backlit TFT display with touchscreen
•3 Year Warranty

Option U01 adds:
•Data logging of peak values, complete traces or screen images from timer, external trigger or limits comparator
•Limit lines and limit patterns with limits comparator
•Sweep triggering from external trigger or limits comparator
•Compensation tables, fixed offsets and 75W compensation
•Capability to show screen contents on a PC


Zusätzliche Information



Aim TTi PSA1302     1,3GHz portable RF Spectrum Analyzer

Aim TTi PSA1302 Produktdatenblatt
